| Frame Material: | Aluminium Casting |
| Nominal Diameter: | 310mm(12in) |
| Nominal Impedance: | 8 ohm |
| Power RMS: | 800W |
| Sensitivity(2.83V/1m): | 102dB |
| Frequency Range: | 45-2500Hz |
| Voice Coll Diameter/Coil Material: | 100mm/Copper |
| Frame Material: | Aluminium Casting |
| Nominal Diameter: | 310mm(12in) |
| Nominal Impedance: | 8 ohm |
| Power RMS: | 800W |
| Sensitivity(2.83V/1m): | 102dB |
| Frequency Range: | 45-2500Hz |
| Voice Coll Diameter/Coil Material: | 100mm/Copper |
| V.C Former Material: | Glass Fiber |
| Voice Coil Winding Width: | 16.5mm |
| Magnet Type/Gsp Depth: | Neodymium/10mm |
| Fs: | 45Hz |
| Re: | 6 ohm |
| Qts: | 0.39 |
| Vas: | 86 Ltr |
| Xmax: | ±7mm |
Standard Package: Product inner box(see the below three styles)+Shipping box(carton box)
Inner box:
Stype 1 : color box
Stype 2: white box
Stype 3:carton box
Customized Package: offered the designe by the customer
