| Frame Material: | Aluminium Casting |
| Nominal Diameter: | 465mm(18in) |
| Nominal Impedance: | 8 ohm |
| Power RMS: | 1000W |
| Sensitivity(2.83V/1m): | 103dB |
| Frequency Range: | 36-2000Hz |
| Voice Coll Diameter: | 100mm |
| Frame Material: | Aluminium Casting |
| Nominal Diameter: | 465mm(18in) |
| Nominal Impedance: | 8 ohm |
| Power RMS: | 1000W |
| Sensitivity(2.83V/1m): | 103dB |
| Frequency Range: | 36-2000Hz |
| Voice Coll Diameter: | 100mm |
| Voice Coll Material: | Glass Fiber/Copper |
| Gsp Depth: | 10mm |
| Voice Coil Winding: | 17.5mm |
| Magnet Type: | 100 oz Ferrite |
| Fs: | 36Hz |
| Re: | 5.2 ohm |
| Qts: | 0.4 |
| Xmax: | ±8mm |
Standard Package: Product inner box(see the below three styles)+Shipping box(carton box)
Inner box:
Stype 1 : color box
Stype 2: white box
Stype 3:carton box
Customized Package: offered the designe by the customer
