| Frame Material: | Aluminium Casting |
| Nominal Diameter: | 465mm(18in) |
| Nominal Impedance: | 8 ohm |
| Power RMS: | 1200W |
| Sensitivity(2.83V/1m): | 103dB |
| Frequency Range: | 25-2000Hz |
| Voice Coll Diameter: | 100mm |
| Frame Material: | Aluminium Casting |
| Nominal Diameter: | 465mm(18in) |
| Nominal Impedance: | 8 ohm |
| Power RMS: | 1200W |
| Sensitivity(2.83V/1m): | 103dB |
| Frequency Range: | 25-2000Hz |
| Voice Coll Diameter: | 100mm |
| Voice Coll Material: | Glass Fiber/Copper |
| Gsp Depth: | 14mm |
| Voice Coil Winding: | 25.6mm |
| Magnet Type: | 125 oz Ferrite |
| Fs: | 28Hz |
| Re: | 5.1 ohm |
| Qts: | 0.27 |
| Xmax: | ±12mm |
Standard Package: Product inner box(see the below three styles)+Shipping box(carton box)
Inner box:
Stype 1 : color box
Stype 2: white box
Stype 3:carton box
Customized Package: offered the designe by the customer
