Frame Material: | Aluminium Casting |
Nominal Diameter: | 320mm(12in) |
Nominal Impedance: | 8 ohm |
Power RMS: | 500W |
Sensitivity(2.83V/1m): | 99dB |
Frequency Range: | 40-3500Hz |
Voice Coll Diameter: | 76mm |
Frame Material: | Aluminium Casting |
Nominal Diameter: | 320mm(12in) |
Nominal Impedance: | 8 ohm |
Power RMS: | 500W |
Sensitivity(2.83V/1m): | 99dB |
Frequency Range: | 40-3500Hz |
Voice Coll Diameter: | 76mm |
Voice Coll Material: | Glass Fiber/Copper |
Gsp Depth: | 10mm |
Voice Coil Winding: | 18.5mm |
Magnet Type: | 70 oz Ferrite |
Fs: | 43Hz |
Re: | 5.8 ohm |
Qts: | 0.22 |
Xmax: | ±8mm |
Standard Package: Product inner box(see the below three styles)+Shipping box(carton box)
Inner box:
Stype 1 : color box
Stype 2: white box
Stype 3:carton box
Customized Package: offered the designe by the customer
